Intelligent Module Discharge Equipment

Equipment introduction

WULING Auto manufacturer this Intelligent Module Discharge Equipment can be used to collect battery voltage data in real time with external sampling line, and the discharge parameters can be set through the screen to realize the discharge of battery module.

Application occasion

Intelligent Module Discharge Equipment is suitable for the rapid discharge of battery modules.

Functional features

Discharge current can be up to 50A, for the rapid discharge of large-capacity bat- teries.

The Intelligent Module Discharge Equipment can carry out discharge equalization,and the equalization voltage bounce is very small.

Safe and reliable equipment, support reverse connection protection, short circuit protection.

● Touch design

With a 4.3-inch touch screen display, you can set the discharge parameters

through the screen, no need to connect to a PC, simple and convenient operation.

● Equipment self-diagnosis

Intelligent Module Discharge Equipment with output short circuit protection, battery undervoltage protection, battery overvoltage protection, single cell reverse connection protection, chassis

over-temperature protection. Protection; equipment with major faults automatically alarm, buzzer, indicator light alarm prompts.

● Discharge  strategy

According to the target voltage equipment intelligent control of the battery dis- charge.

Constant current/constant power discharging, when the difference between the

battery module voltage and the target voltage is large, the battery will be discharged with high current, and when the difference is less than a certain value, the battery will be discharged with low current. When the detected difference is less than a certain value, small current is used to discharge the battery, and the current of both stages can be set.

Technical Parameters
